SPECIFICHE
| NS-5ACL | |||||||||
| Dimensions | 179 x 77.5 x 59.1 mm (7.05 x 3.05 x 2.33") | ||||||||
| Weight | 180 g (6.35 oz) | ||||||||
| Power Supply | 24V, 0.5A Gigabit PoE Supply* | ||||||||
| Max. Power Consumption | 8.5W | ||||||||
| Power Method | Passive PoE (Pairs 4, 5+; 7, 8 Return) | ||||||||
| Gain | 13 dBi | ||||||||
| Networking Interface | 10/100/1000 Mbps Ethernet Port | ||||||||
| Channel Bandwidths | 10/20/30/40/50/60/80 MHz | ||||||||
| Processor Specs | Atheros MIPS 74Kc, 560 MHz | ||||||||
| Memory | 64 MB DDR2 | ||||||||
| Cross-pol Isolation | 20 dB Minimum | ||||||||
| Max. VSWR | 1.8:1 | ||||||||
| Beamwidth | 45° (H-pol) / 45° (V-pol) / 45° (Elevation) | ||||||||
| Polarization | Dual Linear | ||||||||
| Enclosure | Outdoor UV Stabilized Plastic | ||||||||
| LEDs | (1) Power | ||||||||
| Mounting | Pole-Mount (Kit Included) | ||||||||
| Operating Temperature | -40 to 70° C (-40 to 158° F) | ||||||||
| Operating Humidity | 5 to 95% Noncondensing | ||||||||
| RoHS Compliance | Yes | ||||||||
| ESD/EMP Protection | ±24kV Contact/Air | ||||||||
| Shock & Vibration | ETSI300-019-1.4 | ||||||||
| Certifications | CE, FCC, IC | ||||||||
| Operating Frequency (MHz) | |||||||||
| Worldwide | 5150 - 5875 | ||||||||
| Management Radio (MHz) | |||||||||
| Worldwide | 2412 - 2472 | ||||||||
| Output Power: 25 dBm | |||||||||
| 5 GHz TX Power Specifications | 5 GHz RX Power Specifications | ||||||||
| Modulation | Data Rate | Avg. TX | Tolerance | Modulation | Data Rate | Sensitivity | Tolerance | ||
| airMAX ac | 1x BPSK (½) | 25 dBm | ± 2 dB | airMAX ac | 1x BPSK (½) | -96 dBm | ± 2 dB | ||
| 2x QPSK (½) | 25 dBm | ± 2 dB | 2x QPSK (½) | -95 dBm | ± 2 dB | ||||
| 2x QPSK (¾) | 25 dBm | ± 2 dB | 2x QPSK (¾) | -92 dBm | ± 2 dB | ||||
| 4x 16QAM (½) | 25 dBm | ± 2 dB | 4x 16QAM (½) | -90 dBm | ± 2 dB | ||||
| 4x 16QAM (¾) | 25 dBm | ± 2 dB | 4x 16QAM (¾) | -86 dBm | ± 2 dB | ||||
| 6x 64QAM (2/3) | 25 dBm | ± 2 dB | 6x 64QAM (2/3) | -83 dBm | ± 2 dB | ||||
| 6x 64QAM (¾) | 24 dBm | ± 2 dB | 6x 64QAM (¾) | -77 dBm | ± 2 dB | ||||
| 6x 64QAM (5/6) | 23 dBm | ± 2 dB | 6x 64QAM (5/6) | -74 dBm | ± 2 dB | ||||
| 8x 256QAM (¾) | 21 dBm | ± 2 dB | 8x 256QAM (¾) | -69 dBm | ± 2 dB | ||||
| 8x 256QAM (5/6) | 21 dBm | ± 2 dB | 8x 256QAM (5/6) | -65 dBm | ± 2 dB | ||||
